Main line branch terminals FLS 35/9x4 Multicolor

19,61 €
Add to Cart

Main line branch terminals FLS 35/9x4 Multicolor
item-number: 492342



product
code		W1
(mm)		W2
(mm)
492342replaceable color plates16,320,4



In

1×35
1×25
9×4,0
9×2,5
125 A
1 x M8
  9 x M4
Technical data:
 Nominal voltage:
 400 V AC
 Nominal frequency:
 50/60 Hz
 Nominal insulation voltage:
 500 V
 Clamp material:
 brass
 Fastening:
 to be clapped on rail 35 × 7.5 mm
 Fastening torque:
 see Appendix
 Degree of protection:
 IP 20
 Ambient temperature:
 -10 °C…+55 °C
