Main line branch terminals FLS 70/8x10 Multicolor

29,88 €

Main line branch terminals FLS 70/8x10 Multicolor
item-number: 492345



product
code
W1
(mm)
W2
(mm)
492345replaceable color plates32,236,1



In

1×70
1×50
8×10
8×6
192 A
1 x M10
  8 x M6
Technical data:
 Nominal voltage: 400 V AC
 Nominal frequency: 50/60 Hz
 Nominal insulation voltage: 500 V
 Clamp material: brass
 Fastening: to be clapped on rail 35 × 7.5 mm
 Fastening torque: see Appendix
 Degree of protection: IP 20
 Ambient temperature:   -10 °C…+55 °C
