Metal distribution cabinet TFE, steel, 500x400x150 IP55

83,66 €

Metal distribution cabinet TFE, steel, 500x400x150 IP55
item-number: 493078


product
code

H x W x D
(mm)

4930781
500 x 400 x 150 with mounting plate

Due to the employed mounting-plate installation technique, the various devices can be placed into the box as needed.
The metal frame affords perfect stability to the structure. The boxes are delivered with doors and mounting plates.
Doors can be closed by handle. Locks and keys are not part of the delivery. The opening direction of the door is changeable with vertical rotation of the box or relocation of the hinge. The Box are provided at one point. We advise to install devices in our boxes up to max. 800 A rated current.
Dimensions (mm)
Plate thickness (mm)
Height
(L)
Width
(W)
Depth
(H)
Body
Door
Rear wall
500
400
150
1,2
1,2
1,5
